SX-EW53

RM1,950.00
RM1,950.00

This HDBaseT HDMI and VGA/audio extender with bi-directional IR, RS232, and POC transmits up to 70m for 1080P and 40m for 4K@60Hz 4:4:4 over a single Cat5e/6 cable using uncompressed HDBaseT technology.
Total: MYR 1,950.00
SKU: FHE0005
Tags:
Collections:
Fast Nationwide ShippingFree shipping over RM500.
100% Genuine ProductsWe only sell authentic, certified electronics.
Free Tech SupportHelp & troubleshooting 24/7
AVLinkHX-2344Z Set
HX-2344Z Set
SX-SP07S
FoxunHDSX-SP07S
SX-EW53
RM1,950.00
RM1,950.00
  • The SX-EW53 is an HDBaseT wallplate extender that takes either an HDMI or VGA+audio source and sends it up to 70m over a single Cat5e/6 cable, with IR, RS232 control and Power over Cable built in for clean, single-cable installs.
  • Dual HDMI/VGA Input WallplateAccepts either an HDMI or a VGA+audio source from a wall-mounted plate.
  • Long-Distance HDBaseT TransmissionExtends up to 70m at 1080P or 40m at 4K@60Hz 4:4:4 over a single Cat5e/6 cable.
  • Bi-Directional IR & RS232 ControlPasses IR and RS232 control signals between rooms alongside the video.
  • Power over Cable (PoC)Powers the receiver over the same Cat cable, removing the need for a second power supply at the display end.
  • Single-Cable InstallationRuns on standard Cat5e/6 cabling, simplifying wall and ceiling installs versus long HDMI or VGA runs.
  • Inputs
    • HDMI
    • VGA + Audio
  • Transmission
    • Technology: Uncompressed HDBaseT
    • Distance: Up to 70m @1080P
    • Distance: Up to 40m @4K@60Hz (YUV 4:4:4)
    • Cable: Single Cat5e/6 cable
  • Control & Power
    • Bi-Directional IR
    • RS232
    • POC (Power over Cable)
    •
