TeamJoin TRS10

Enquire for price

Computing engine and touch console for Microsoft Teams Rooms, delivering a certified all-in-one meeting room experience.
Enquire on WhatsApp Enquire by email

Email not opening? Write to support@avprojectorroom.com and quote "TeamJoin TRS10".
Total: MYR 0.00
Tags:
Collections:
Fast Nationwide ShippingFree shipping over RM500.
100% Genuine ProductsWe only sell authentic, certified electronics.
Free Tech SupportHelp & troubleshooting 24/7
ViewSonicViewBoard IFP8634
ViewBoard IFP8634
ViewBoard IN6503-1C
ViewSonicViewBoard IN6503-1C
TeamJoin TRS10
Enquire for price
  • A complete, certified-for-Microsoft-Teams-Rooms compute and control bundle — TeamJoin TRS10 pairs a purpose-built Windows 11 IoT compute engine with a 10.1" touch console, so any room becomes a fully managed Teams Rooms space without sourcing components separately.
  • Certified for Microsoft Teams RoomsShips with Windows 11 IoT Enterprise and Teams Rooms pre-installed and validated by Microsoft for out-of-the-box reliability.
  • Capable Intel Core ComputeAn Intel Core i3-1220P with Turbo Boost to 4.4GHz, 8GB RAM, and a 128GB SSD comfortably runs Teams calls, content sharing, and room peripherals.
  • Dedicated 10.1" Touch ConsoleA responsive 10-point capacitive touchscreen with under-25ms latency makes starting and managing meetings effortless.
  • Built-In Room Occupancy SensingThe console's PIR motion sensor supports 24/7 people-presence detection for smart room scheduling.
  • Simple 4K Video OutputHDMI 4K@60Hz with CEC control and USB-C DisplayPort output drive the room display without extra adapters.
  • Console-to-Engine IngestThe touch console accepts its own HDMI and USB-C video input, letting a guest laptop present through the console when needed.
  • Clean Cable RunA long-reach USB-C cable and VESA mounting bracket keep the compute engine tucked behind the display with a single cable to the console.
  • Computing Engine (MPC310-W31-TU)
    • Processor: Intel Core i3-1220P (1.5GHz, Turbo Boost up to 4.4GHz) with Intel UHD Graphics
    • Memory: 8GB DDR4 SODIMM (dual channel)
    • Storage: 128GB M.2 2280 SSD (SATA)
    • Operating System: Windows 11 IoT Enterprise (x64) with Microsoft Teams Rooms pre-installed
    • Wireless: Built-in Bluetooth 5.3 (no Wi-Fi)
  • Touch Console (MRC1010-TN)
    • Display: 10.1" touch panel, 1920 x 1200 resolution, 60Hz refresh
    • Brightness: 300 cd/m²
    • Backlight Lifespan: 20,000 hours
    • Touch: 10-point capacitive touch, <25ms touch-down latency
    • Touch Accuracy: ±1mm center, ≤2.5mm edges
    • Sensor: Built-in PIR motion sensor (24/7 room-occupancy detection)
  • Connectivity
    • Computing Engine: 4x USB 3.0 Type-A, 1x USB 3.0 Type-C (DisplayPort 4K@30Hz, 12V/2A PD), 1x RJ45 Gigabit Ethernet, 1x HDMI output (4K@60Hz with CEC), 1x audio combo jack
    • Touch Console: 1x USB 2.0, 1x HDMI ingest, 1x USB-C (DisplayPort in), audio output
  • Power & Certification
    • Power Input: AC 100-240V, 50/60Hz
    • Power Consumption: 111.9W max / 1.5W standby
    • Certification: Certified for Microsoft Teams Rooms
  • What's in the Box
    • Computing Engine (MPC310-W31-TU)
    • Touch Console (MRC1010-TN)
    • VESA mounting bracket for computing engine
    • 1.8m power cord
    • 1.5m HDMI cable
    • 5m USB Type-C cable
    • Quick start guides

    • Download Brochure (PDF)
